PTB Settings Tab

The Settings tab of the NIF Toolbar GUI allows the user to launch various settings apps to quickly load, edit and save variables related to specific aspects of behavioral experiments and associated hardware. The variables controlled by each app in the Settings tab are saved to a unique field of the Params object, as listed in the table below. Click on the icon or name of each setting GUI to view it’s documentation, or click on the output structure to see the list of fields within each settings output structure.

Icon	Setting GUI	Output Structure	Brief Description
	Display	Params.Display	Configure visual display geometry and appearance for both subject and experimenter.
	Datapixx	Params.DPx	Set analog and digital IO channels for the DataPixx interface box.
	Eye tracking	Params.Eye	Set parameters for eye-tracker calibration in order to convert analog eye signals into screen coordinates.
	Reward	Params.Reward	Set parameters for liquid reward delivery schedule.
	Keyboard	Params.Keys	Set experimenter keyboard shortcuts that are active while the experiment is running.
	Save data	Params.Save	Set parameters for saving data from Matlab during experiments.
	GitHub	Params.Git	Set parameters for pulling and pushing PTB code updates from GitHub.
	National Instruments	Params.NI	Set parameters for communication with National Instruments (NI) data acquisition systems.
